Chapter 2 Troubleshooting
2.3 Error Code FIP
2-86
FIP2.13 MOTOR DISP (PL5.1.9)
Step Check and Action Yes No
Parts considered to be the cause
DRIVE ASSY DISP (PL5.1.5)
MOTOR DISP (PL5.1.9)
HARNESS ASSY DISP MOT (PL18.3.10)
PWBA MCU (PL18.2.2)
1
Check for foreign substances in the MOTOR DISP Drive
Section
Are there any foreign substances in the MOTOR DISP
Drive Section?
Remove the
foreign sub-
stances
Go to Step 2.
2
Check the shape of the DRIVE ASSY DISP
Is the DRIVE ASSY DISP damaged?
Replace the
DRIVE ASSY
DISP
Go to Step 3.
3
Check connector connection
Check the connection between the MOTOR DISP and the
PWBA MCU.
Is the HARNESS ASSY DISP MOT (P/J111-P/J11) con-
nected securely?
Go to Step 4.
Securely con-
nect the HAR-
NESS ASSY
DISP MOT
(P/J111-P/J11)
4
Check after replacing the MOTOR DISP
Replace the MOTOR DISP. (REP 5.3)
Does an error occur?
Go to Step 5. End of work.
5
Check after replacing the HARNESS ASSY DISP MOT
Replace the HARNESS ASSY DISP MOT.
Does an error occur?
Replace the
PWBA MCU.
(REP 18.2)
End of work.
To Next Page
