Chapter 6 General
6.6 IOT Diag
6-52
6.6.3.2 NVM Saving (Save NVM to ESS)
Saves the IOT NVM information to the ESS NVM.
If the IOT NVM information has never been changed using [Edit NVM}, [Save NVM to ESS] cannot be exe-
cuted.
Procedure
1 Enter the CE mode. (See "6.4.2 How to Enter the CE Mode".)
2 Confirm that [Printer Diag] is selected, and then press the [OK] button.
3 Use the [T] button to select [IOT Diag], and then press the [OK] button.
4 Use the [T] button to select [NVM Settings], and then press the [OK] button.
5 Use the [T] button to select [Save NVM to ESS], and then press the [OK] button.
6 Press the [OK] button.
7 Press the [C(Clear)] to return to the [Printer Diag] screen, and then exit the CE mode.
(See "6.4.4 How to Exit the CE Mode".)
Printer Diag
IOT Diag
IOT Diag
Digital Input
IOT Diag
NVM Settings
NVM Settings
Edit NVM
NVM Settings
Save NVM to ESS
Save NVM to ESS
OK?
Save NVM to ESS
Processing
Save NVM to ESS
Saved
To Next Page
