Chapter 2 Troubleshooting
2.3 Error Code FIP
2-72
FIP1.26 093-925 Toner CRUM Error
093-926 Toner CRUM ID Error
093-928 Toner Type Error
093-973 Toner Detached
Step Check and Action Yes No
Parts considered to be the cause
TONER CARTRIDGE (PL8.1.2)
CONNECTOR ASSY-CRUM TONER (PL5.1.2)
HARNESS ASSY XERO CRUM (PL18.3.12)
PWBA MCU (PL18.2.2)
1
Check the installation of the TONER CARTRIDGE
Is the Drum Cartridge installed properly, with no foreign
substances at the contact point between the CRUM in the
TONER CARTRIDGE and the CONNECTOR ASSY-CRUM
TONER?
Go to Step 2.
Reinstall the
TONER CAR-
TRIDGE
2
Check the TONER CARTRIDGE
Is the TONER CARTRIDGE, which is installed in the
device, a genuine product?
Go to Step 3.
Replace the
TONER CAR-
TRIDGE with a
genuine prod-
uct
3
Check the CRUM part of the TONER CARTRIDGE
Is the connection terminal of the CRUM part in the TONER
CARTRIDGE damaged?
Replace the
TONER CAR-
TRIDGE
Go to Step 4.
4
Check the CONNECTOR ASSY-CRUM TONER
Is the connection terminal of the CONNECTOR ASSY-
CRUM TONER damaged?
Replace the
CONNECTOR
ASSY-CRUM
TONER
Go to Step 5.
5
Check connector connection
Check the connection between the CONNECTOR ASSY,
the CRUM TONER, and the PWBA MCU.
Is the HARNESS ASSY XERO CRUM (P/J253-P/J25) con-
nected securely?
Go to Step 6.
Securely con-
nect the HAR-
NESS ASSY
XERO CRUM
(P/J253-P/J25)
6
Check after replacing the TONER CARTRIDGE
Replace the TONER CARTRIDGE.
Does an error occur?
Go to Step 7. End of work.
7
Check after replacing the CONNECTOR ASSY-CRUM
TONER
Replace the CONNECTOR ASSY-CRUM TONER.
Does an error occur?
Go to Step 8. End of work.
8
Check after replacing the HARNESS ASSY XERO CRUM
Replace the HARNESS ASSY XERO CRUM.
Does an error occur?
Replace the
PWBA MCU.
(REP 18.2)
End of work.
To Next Page
