Chapter 2 Troubleshooting
2.3 Error Code FIP
2-71
FIP1.25 093-922 Toner Low Density
Step Check and Action Yes No
Parts considered to be the cause
TONER CARTRIDGE (PL8.1.2)
Drum Cartridge [XERO ASSY] (PL8.1.1)
PWBA MCU (PL18.2.2)
1
Check after reinstalling the TONER CARTRIDGE
Remove the TONER CARTRIDGE, shake it a few times,
and then reinstall it.
Does an error occur?
Go to Step 2. End of work.
2
Check the installation status of the Drum Cartridge
Remove the Drum Cartridge.
Is the contact points of the Drum Cartridge clean, and cor-
rectly installed?
Go to Step 3.
Clean the con-
tact points
Reinstall the
Drum Car-
tridge
3
Check after replacing the TONER CARTRIDGE
Replace the TONER CARTRIDGE.
Does an error occur?
Go to Step 4. End of work.
4
Check after replacing the Drum Cartridge
Replace the Drum Cartridge.
Does an error occur?
Replace the
PWBA MCU.
(REP 18.2)
End of work.
To Next Page
