Chapter 2 Troubleshooting
2.4 Other FIP
2-90
5
Check after replacing the SOLENOID FEED MSI
Replace the SOLENOID FEED MSI.
Does an abnormal noise occur while feeding paper from
the MSI?
Go to Step 6. End of work.
6
Check after replacing the CST FEED CLUTCH
Replace the CST FEED CLUTCH.
Does an abnormal noise occur while feeding paper from
the Tray 1?
Go to Step 7. End of work.
7
Check after replacing the REGI. CLUTCH
Replace the REGI. CLUTCH.
Is there any abnormal noise from the device?
FIP-N1 Abnor-
mal Noise:
When Power is
Turned OnGo
to2.4.1
End of work.
Step Check and Action Yes No
To Next Page
