Chapter 3 Image Quality Troubleshooting
3.2 Image Quality Troubleshooting
3-23
9
Checking the Transfer Unit for connection.
Remove the Transfer Unit.
Are the Plate Spring BTR on HVPS dirty or deformed?
Clean up the
Plate Spring BTR
or Replace the
HVPS (REP
18.3), then go to
step 10.
Go to step 10.
10
Checking after resetting the Transfer Unit.
Reseat the Transfer Unit.
Is the image printed correctly?
End of work.
Replace the
Drum Cartridge.
Step Check and Action Yes No
To Next Page
