Fuji Xerox DocuPrint M355df User Manual

Chapter 3 Image Quality Troubleshooting
3.2 Image Quality Troubleshooting
3-26
9
Execute the Clean Developer.
(Refer to [Clean Developer] in [Maintenance] of [Admin
Menu].)
Is the image printed correctly?
End of work. Go to step 10.
10
Check the installation of the Drum Cartridge.
Is the Drum Cartridge installed properly, with no foreign sub-
stances at the contact point between the ATC Sensor in the
Drum Cartridge and the CONNECTOR ASSY XERO?
Go to Step 11.
Reinstall the
Drum Cartridge,
then go to step
11.
11
Check the ATC Sensor part of the Drum Cartridge.
Is the connection terminal of the ATC Sensor part in the Drum
Cartridge damaged?
Replace the
Drum Cartridge,
then go to step
12.
Go to Step 12.
12
Check the CONNECTOR ASSY XERO.
Is the connection terminal of the CONNECTOR ASSY XERO
damaged?
Replace the
CONNECTOR
ASSY XERO
(REP 5.4), then
go to step 13.
Go to Step 13.
13 Is the image printed correctly? End of work. Go to step 14.
14
Checking after resetting the Drum Cartridge.
Reseat the Drum Cartridge.
Is the image printed correctly?
End of work. Go to step 15.
15
Checking after resetting the HVPS.
Reseat the HVPS.
Is the image printed correctly?
End of work. Go to step 16.
16
Checking after replacing the Drum Cartridge.
Replace the Drum Cartridge.
Is the image printed correctly?
End of work.
Replace the
HVPS. (REP
18.3)
Step Check and Action Yes No
