Chapter 3 Image Quality Troubleshooting
3.2 Image Quality Troubleshooting
3-33
9
Check the CONNECTOR ASSY XERO.
Is the connection terminal of the CONNECTOR ASSY XERO
damaged?
Replace the
CONNECTOR
ASSY XERO
(REP 5.4), then
go to step 10.
Go to Step 10.
10 Is the image printed correctly? End of work. Go to step 11.
11
Checking after replacing the Drum Cartridge.
Replace the Drum Cartridge.
Is the image printed correctly?
End of work.
Replace the
printer.
Step Check and Action Yes No
To Next Page
