Fuji Xerox DocuPrint M355df

Chapter 4 Disassembly / Assembly and Adjustment
4.2 Removal / Replacement
4-75
NOTE
When installing the GEAR SEGMENT MSI 1 and GEAR SEGMENT MSI 2, fit the bosses on the
GEAR SEGMENT MSI 1 into the holes on the GEAR SEGMENT MSI 2.
