Chapter 1 Service Call Procedure
1.4 TRIM Check List
1-9
3.1 FUSING UNIT CL O: 100K REP 7.1
• Check that Heat Roll/Pressu
re Belt
are not scratched.
Replace where necessary.
To reset the counter, refer to
Chapter 6 (Life), and initialize the
life counter for Fusing PV/Fusing
Heattime.
3.2
Drum Cartridge
(XERO ASSY)
C O: 100K*3 REP 8.1
• Visual check only.
Do not touch the Drum Cartridge
(XERO ASSY) with hand.
Do not use solvents such as Drum
Cleaner.
(It will take longer time to
resume servicing.)
*3: To detect the life end of the
Drum, Drum rotation count
(Cycle), waste toner estimate, and
PV value count are used.
4 DADF CL
O: 35K
Feed*2
REP 21.3
•
Clean any paper dust and contami-
nation in the paper path and on the
jam
sensor.
• Check and clean the +Feed Roll/
Nudger
Roll and SEPARATION
PAD in the ROLLER ASSY DADF.
Replac
e the KIT DADF PICK UP
MODULE (ROLLER ASSY
DADF+SEP
ARATION PAD) if nec-
essary.
*2: Decide whether to reset the
counter based on the counter for
the FUSING UNIT. (Replace
together with the FUSING UNIT)
Table 1-1
No Servicing Item
Every
Time
Replace-
ment Interval
Removal/Re-
placement
No.
Service Details
To Next Page
