Fuji Xerox DocuPrint M355df User Manual

Chapter 7 Wiring Data
7.1 Plug/Jack Location List
7-2
233 G-154 Connects FUSING UNIT (PL7.1.1)and HARNESS ASSY FSR (PL18.3.9)
240 I-109 Connects PWBA LVPS (PL18.1.5) and HARNESS ASSY REAR FAN (PL18.3.16)
241 J-109 Connects PWBA LVPS (PL18.1.5) and LVPS FAN (PL4.1.1)
243 J-181
Connects HARNESS ASSY FDR DRAWER 1 (PL10.1.18) and HARNESS ASSY
OP FDR (PL18.3.8)
250 J-109 Connects PWBA LVPS (PL18.1.5) and HARNESS ASSY TEST RLY (PL18.3.14)
251 F-104 HARNESS ASSY TEST RLY (PL18.3.14) Test Port
253 F-168
Connects CONNECTOR ASSY-CRUM TONER (PL5.1.2) and HARNESS ASSY
XERO CRUM (PL18.3.12)
254 D-166
Connects CONNECTOR ASSY XERO (PL5.1.10) and HARNESS ASSY XERO
CRUM (PL18.3.12)
261 G-122 Connects HVPS (PL18.2.5) and HARNESS ASSY HV (PL18.3.13)
271 E-152
Connects EXIT SENSOR (PL17.1.1) and HARNESS ASSY SENS EXIT
(PL18.3.15)
401 C-111 Connects PWBA ESS (PL18.1.2) and KIT MEMORY (PL18.1.18)
402 D-113 Connects PWBA ESS (PL18.1.2) and PWBA ASSY FAX(PL18.1.10)
411 A-111 PWBA ESS (PL18.1.2) USB Port
412 A-112 Connects PWBA ESS (PL18.1.2) and WIRELESS ADAPTER (PL18.1.17)
413 A-111
Connects PWBA ESS (PL18.1.2) and HARNESS ASSY FRONT-USB Z-
AIO(PL18.1.8)
414 A-110 PWBA ESS (PL18.1.2) Ethernet Port
419 H-182
Connects PWBA ASSY OPT TRAY (PL10.1.5) and HARNESS ASSY FDR
DRAWER 1 (PL10.1.18)
420 G-182
Connects PWBA ASSY OPT TRAY (PL10.1.5) and HARNESS ASSY OP L
COMP (PL10.2.3)
421 E-112 Connects PWBA ESS (PL18.1.2) and HARNESS ASSY ESS (PL18.3.3)
422 E-112 Connects PWBA ESS (PL18.1.2) and HARNESS VIDEO (PL2.1.3)
422 G-182
Connects PWBA ASSY OPT TRAY (PL10.1.5) and HARNESS ASSY TRAY MOT
(PL10.1.11)
431 E-111
Connects PWBA ESS (PL18.1.2) and HARNESS ASSY FRONT-USB Z-
AIO(PL18.1.8)
441 E-110
Connects PWBA ESS (PL18.1.2) and HARNESS ASSY ESS PWR AIO
(PL18.3.4)
451 A-110 Connects PWBA ESS (PL18.1.2) and IIT ASSY (PL21.1.14)
452 D-110 Connects PWBA ESS (PL18.1.2) and IIT ASSY (PL21.1.14)
453 C-110 Connects PWBA ESS (PL18.1.2) and DADF ASSY (PL21.1.1)
501 D-134 Connects ROS ASSY (PL2.1.1)and HARNESS ROS-MCU (PL2.1.2)
502 D-134 Connects ROS ASSY (PL2.1.1)and HARNESS VIDEO (PL2.1.3)
2401 D-155
Connects Rear Fan [FAN SUB] (PL19.2.9)and HARNESS ASSY REAR FAN
(PL18.3.16)
Table 7-1
P/J Coordinates Description
