Chapter 7 Wiring Data
7.5 Interconnection Wiring Diagram of Parts
7-27
Table 7-7
Signal line name Description
CLOCK TONER
DATA TONER
Control signal of the TONER CRUM
DATA XERO
CLOCK XERO
Control signal of the XERO CRUM
ATC VOUT Toner patch density data measured by the ATC Sensor
MSI NO PAPER SNR Paper detect signal by the MSI No Paper Sensor
CST NO PAPER SNR Paper detect signal by the CST No Paper Sensor
REGI SNR Paper detect signal by the Regi. Sensor
TEMP
The temperature data in the machine that is measured by the Temp.
Sensor
HUMI
The humidity data in the machine that is measured by the Humi.
Sensor
TR+IMON
DA CR
DA DBDC
DA DBAC
DA TR+
DA TR-
HV CLK1
HV CLK2
Control signal of the HVPS
To Next Page
