Fuji Xerox DocuPrint M355df User Manual

Chapter 7 Wiring Data
7.5 Interconnection Wiring Diagram of Parts
7-29
Table 7-8
Signal line name Description
STS MAIN
Temperature data measured by Temp. Sensor (Main) for controlling
temperature
STS SIDE
Temperature data measured by Temp. Sensor (Side) for controlling
temperature
HEAT1
HEATEN
Control signal of the Heater
ALM R FAN
R FAN LOW
R FAN STOP
Control signal of the Rear Fan [FAN SUB]
EXIT SENSOR Paper detect signal of the Fusing Exit by the EXIT SENSOR
