Chapter 7 Wiring Data
7.5 Interconnection Wiring Diagram of Parts
7-35
Table 7-11
Signal line name Description
FEED TRAY SENS
FEED RXD
FEED TXD
Control signal of the PWB ASSY OPT TRAY
OP FEED MOTOR ON
OP FEED MOTOR ALARM
OP FEED MOTOR CLOCK
OP FEED MOTOR GAIN
Drive control signal of the MOTOR ASSY OPTION
FEED ROLL CLUTCH ON ON/OFF signal of the CLUTCH ASSY OPT FEED
PAPER SENSED SIGNAL Paper detect signal by the No Paper Sensor
