TX2550 M4 Upgrade and Maintenance Manual 241
Hard disk drive (HDD) / solid state drive (SSD)
7.5 HDD/SSD extension boxes
7.5.1 HDD/SSD extension boxes overview
7.5.1.1 8x 2.5-inch HDD/SSD extension box
Figure 155: 8x 2.5-inch HDD/SSD extension box
I The 8x 2.5-inch HDD/SSD extension box occupies accessible drive bays
2 and 3 (see figure 270).
7.5.1.2 4x 3.5-inch HDD/SSD extension box
Figure 156: 4x 3.5-inch HDD/SSD extension box
I The 4x 3.5-inch HDD/SSD extension box occupies accessible drive bays
1, 2 and 3 (see figure 270).
