292 Upgrade and Maintenance Manual TX2550 M4
Expansion cards and backup units
9.1 Basic information
Figure 197: PCI slot overview - system board
I For system relevant information, see the hardware configurator of your
server available online at the following address:
http://ts.fujitsu.com/products/standard_servers/index.htm
For Japan:
http://www.fujitsu.com/jp/products/computing/servers/primergy/
external connectors
SERIAL
SATA ODD
JP2
JP1
Slot OCP module
Micro
SD
SSD2
M.2
M.2
SSD1
TPM
iRMC
S5
LAN
Management
VGA
LAN 1
LAN 1/M
USB 3.0
VPP CP
VPP CP
LAN 1
LAN 2 /
USB 3.0
Slot 9 (CPU 2)
Slot 8 (CPU2)
Slot 2 (CPU 1)
Slot 1 (CPU 1)
Slot 4 (CPU 1) - slot riser card
Slot 3 (CPU 1)
JP7 JP8
4-7
Buzzer
iRMC
S5
Slot riser card
Riser card
Slot 7
Slot 6
Slot 5
If riser card used:
Battery
VROC
