Fujitsu PRIMERGY TX2550 M4 - Server Front

502 Upgrade and Maintenance Manual TX2550 M4
Appendix A
18.2.2 Server front
18.2.2.1 Indicators on the front panel
Figure 364: Indicators on the front panel
Pos. Label Indicator Status Description
1 ID
ID indicator,
see also
"iRMC-
related
status
signals" on
page 504
blue on
The server has been highlighted using
ServerView Operations Manager,
iRMC web interface or the ID button on
the front panel for easy identification.
blue
flashing
The server has been highlighted for
easy identification using the iRMC
(AVR) with disabled local VGA output.
2 [CSS]
CSS
indicator
off
No critical event detected (CSS
component).
orange on
Prefailure event detected (CSS
component).
For HDDs see also "HDD prefailure
detection" on page 505
orange
flashing
CSS component failure detected.
