Fujitsu PRIMERGY TX2550 M4 - Removing the Serial Interface

Bestellnummer Bearbeitungsstand 463
Serial interface
15.1.2 Removing the serial interface
15.1.2.1 Preliminary steps
Ê "Shutting down the server" on page 52
Ê "Disconnecting the power cord" on page 53
Ê "Getting access to the component" on page 54
15.1.2.2 Removing the serial interface
Ê Remove the two bolts (see figure 329) and take out the serial interface.
I The rectangular break-out remains open.
Ê Disconnect the serial interface cable from the system board connector
"SERIAL" (see figure 328).
15.1.2.3 Concluding steps
Ê "Reassembling" on page 68
Ê "Connecting the power cord" on page 81
Ê "Switching on the server" on page 82
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools: hexagon screw driver 5 mm
