Fujitsu PRIMERGY TX2550 M4 - Replacing a Fan Module (High Performance Variant)

TX2550 M4 Upgrade and Maintenance Manual 287
Fans
8.2 Replacing a fan module (high performance
variant)
8.2.1 Preliminary steps
Ê "Locating the defective server" on page 49
Ê "Getting access to the component" on page 54
Ê "Locating the defective component" on page 51
8.2.2 Removing the defective system fan module
Figure 195: Removing the fan module
Ê Take the fan module by the two handles (1).
Customer Replaceable Unit
(CRU)
Hardware: 5 minutes
Tools: tool-less
