TX2550 M4 Upgrade and Maintenance Manual 417
System board and components
14.3 Trusted Platform Module (TPM)
There are different TPM kits available. The procedures of installing, removing
and replacing are identic.
Figure 298: TPM SPI installation kit
1 TPM SPI (Trusted Platform
Module)
3 Special screw for TPM
2 TPM spacer
I The black TPM spacer is
not used in this server.
4 TPM bit insert for TPM special
screw
/
