Fujitsu PRIMERGY TX2550 M4 - Ultraslim ODD in Ultraslim ODD Adapter

398 Upgrade and Maintenance Manual TX2550 M4
Accessible drives
Ê "Connecting the power cord" on page 81
Ê "Switching on the server" on page 82
12.6 Ultraslim ODD in ultraslim ODD adapter
12.6.1 Installing the ultraslim ODD
12.6.1.1 Preliminary steps
Ê "Shutting down the server" on page 52
Ê "Disconnecting the power cord" on page 53
Ê "Getting access to the component" on page 54
I The front cover only needs to be removed in order to remove
accessible drive dummy covers.
Ê "Removing the system air duct" on page 67
Ê If applicable, "Removing the riser module" on page 84
Ê If applicable, remove the expansion card, see section "Removing an
expansion card" on page 318.
Ê Remove the fan bridge, see section "Handling fan bridges" on page 90.
Ê If applicable, "Removing the 4x 3.5-inch HDD extension box" on page 255
Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
Tools: – Phillips PH0 / (+) No. 0 screw driver
– Slotted screw driver (for bending in or out accessible drive
mounting brackets)
