TX2550 M4 Upgrade and Maintenance Manual 481
17 Cabling
17.1 Replacing the intrusion switch cable
17.1.1 Preliminary steps
Ê "Locating the defective server" on page 49
Ê "Shutting down the server" on page 52
Ê "Disconnecting the power cord" on page 53
Ê "Getting access to the component" on page 54
Ê "Removing the system air duct" on page 67
Ê Remove the fan bridge, see section "Handling fan bridges" on page 90.
Field Replaceable Unit
(FRU)
Average task duration:
10 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver
