6.2 Starting and Ending Measurement
136
Why is a waveform not displayed?
The measurement waveform may have gone out of the display range. Change the display
upper limit and display lower limit settings on the
[Channel] tab of the display settings win-
dow to match the measurement values.
See "7.1 Changing the Waveform Display Range" (p. 140).
How do I check the measurement value at any point of a waveform?
Click the tool button on the main screen to display cursors A and B. You can confirm the
measurement value of a specific position of a cursor on the
[Cursor] tab of the display set-
tings window.
See "7.2 Checking Cursor Values" (p. 141).
How do I add graduations (scale) to the graph?
On the [Display Setting] tab in the display settings window, set gauge display to ON.
See "7.3 Changing Display Settings" (p. 142).
How do I split the waveform display area into two?
On the [Display Setting] tab in the display settings window, set split screen to ON.
See "7.3 Changing Display Settings" (p. 142).
How do I add a mark to a waveform?
Click the tool button on the main screen to display an event mark. You can then click on the
waveform to add an event mark.
See "7.5 Event Mark Function" (p. 153).
