10.13 Reading and Writing a Setting File
208
This section describes using the instrument to read setting conditions saved on a
CF card.
1. Turn the power on while pressing
and then release the key
when the model name and version
appear in the display area.
The instrument enters setting mode.
2. Press multiple times until the following setting file reading screen
appears.
3. Open the cover of the CF card slot, and fully insert a CF card.
4. Close the cover, and confirm that the CF card access LED lights green.
5. Press to save the setting conditions to the CF card.
6. Press multiple times until the following setting mode end screen
appears.
7. Press to end setting mode.
10.13.2 Reading a Setting File
• Only place one setting file in the root directory of the CF card. It will not be pos-
sible to read a setting file if there are two or more setting files.
• It is not possible to read a setting file saved with the supplied software Logger
Utility.
• Make the unit configuration of the 8423 that will read the setting file the same
as that of the 8423 that was the copy source of the setting file. Measurement
cannot be performed properly if the unit configurations are not the same.
