9.2 Settings for Waveform Print Options
177
Chapter 9 Printing
9
To select the various waveform print options. To select, click the check box to
insert a check mark.
Ch Marker:
Prints CH number near the waveform as a CH marker.
Print with comment:
Prints comment near the waveform as a Ch marker.
Gauge:
Prints the gauge (graduations) in the left side of the waveform print area. The
number of gauges that will be printed is the same as the number of gauges dis-
played in the waveform display portion.
9.2 Settings for Waveform Print Options
Check
Can only be se-
lected when [Ch
Marker] is
checked.
Can only be se-
lected when
[Gauge] is
checked.
Selectable Items Explanations
First page only Print gauge in the first page only.
All pages Print gauge in all pages.
