Appendix 2 Version Update
A2
You can perform a key operation on the instrument to update the ROM and
FPGA versions of the instrument.
1. Turn the power on while pressing
and then release the key
when the model name and version
appear in the display area.
The instrument enters setting mode.
2. Press multiple times until the following version update screen
appears.
3. Open the cover of the CF card slot, and fully insert a CF card containing
the version update file.
Place just one version update file in the root directory of the CF card. If there are
2 or more version updates, the version update will not be possible.
4. Close the cover, and confirm that the CF card access LED lights green.
5. Press to start the version update.
A version update takes approximately 4 minutes.
6. When the following version update end screen appears, turn the power off
and then back on again.
7. Eject the CF card from the card slot.
Appendix 2 Version Update
• Be sure to close the cover after inserting a CF card. If the cover is not closed,
the version update file cannot be read.
• Never turn the power off during a version update.
• For information on version update files, contact your dealer or Hioki
representative.
