10.11 Self Check
197
Chapter 10 Setting Method for Logger
10
If you perform a self check and the "FAIL" message appears or some kind of
abnormality is found, the instrument needs to be repaired.
This section describes checking the internal memory (ROM) of the instrument.
The result is displayed in the display area.
1. Turn the power on while pressing
and then release the key
when the model name and version
appear in the display area.
The instrument enters setting mode.
2. Press multiple times until the following ROM check screen appears.
3. Press to start the check.
If the result is normal, "PASS" is displayed. If the result is abnormal, "FAIL" is
displayed.
4. Press to end the display of the result.
5. Press multiple times until the following setting mode end screen
appears.
6. Press to end setting mode.
10.11Self Check
10.11.1 ROM Check
To Next Page
