10.4 Time
189
Chapter 10 Setting Method for Logger
10
This section describes setting the time of the internal clock of the instrument.
1. Turn the power on while pressing
and then release the key
when the model name and version
appear in the display area.
The instrument enters setting mode.
2. Press multiple times until the following time setting screen appears.
3. Press to move the flashing cursor to the position to change.
Each press of the key moves the flashing cursor to the right.
4. Press to increase the value at the flashing cursor in increments of 1.
The value cannot be decremented.
5. Press to move the flashing cursor to [SET], and press to con-
firm the setting.
6. Press multiple times until the following setting mode end screen
appears.
7. Press to end setting mode.
10.4 Time
