7.7 Displaying the Channel List
159
7
Chapter 7 Analyzing Measurement Data
The channel list allows you to check information such as the waveform color of each channel. You can also
reduce the number of display channels.
1. Click the [Channel List] tab on the right side of the main screen to open the settings window.
2. When you want to reduce the number of display channels, set the channels to display with the
narrow down feature.
3. When other than the ALL sheet is selected, channel display can be set to OFF.
7.7 Displaying the Channel List
Click
Display color
Channel [Unit]
Selectable Items Explanations
Display Channel Priority
Give priority to displaying the waveforms displayed in the current display
sheet.
Display Channel Only Display only the waveforms displayed in the current display sheet.
All Channels Display all channels.
To Next Page
