8.3 Automatically Transferring Measurement Data to Excel
171
8
Chapter 8 Saving and Reading Data
While measuring with the Logger Utility, data can be automatically transferred to
Excel in real time.
1. In the menu bar, select [File]-[Transfer real time data to Excel...].
The [Real time data transfer to Excel] dialog appears.
2. Select [Transfer real time data to Excel].
3. Select which channels' data to transfer to Excel.
4. Enter the first cell for data transfer to Excel.
Data is transferred to Excel starting with the cell entered here. Enter a valid
Excel cell number, from [A1] to [IV65000].
5. Enter the maximum number of data values to be transferred to Excel.
6. Select the time axis label type from the list.
7. To repeat data transfer from the line specified in Step 4 after the amount of
data specified in Step 5 has been transferred to Excel
8. Click [OK].
8.3 Automatically Transferring Measurement
Data to Excel
8.3.1 Real-Time Transfer Settings
Selectable Items Explanations
Absolute Time Display absolute time from the start of measurement.
Relative Time Display relative time from zero at the start of measurement.
Second
Display relative time in seconds from zero at the start of measurement.
Point
Display relative time as the number of data points from zero at the
start of measurement.
(5) Inputs
(6) Select
(2) Check
(7) Check
(8) Check
(4) Inputs
(3) Select
