Hioki 8423 User Manual

2.1 Installing Logger Utility
18
Follow the procedure below to install Logger Utility. This explanation is for install-
ing the software on Windows XP. The messages displayed may differ slightly
depending on other operation system or settings you are using.
1. Start up Windows.
Exit all running applications.
2. Insert the included CD into the computer's CD-ROM drive, the installer run
automatically.
If the installer do not start, execute “Setup.exe” from the CD-ROM drive.
In Vista, Although the dialog which ask for installation permission of application,
click
[Allow].
2.1 Installing Logger Utility
Important
If you are running software such as antivirus software, be sure to end
the software before you start the installation. The installation may not
be performed properly if antivirus software is running.
Click

Hioki 8423 Specifications

General

Interface	RS-232C
Storage Media	Internal memory
Accuracy	±0.1% of full scale
Power Supply	AC adapter or AA alkaline batteries x 4
Thermocouple	K, J, T, E, R, S, B, N
Measurement Parameters	Voltage
Current Range	Requires clamp-on sensor (optional)
Operating Temperature	0°C to 40°C
