1.1 Product Overview
9
1
Chapter 1 Overview
The 8423 Memory HiLogger is a computer based data collection instrument. A
combination of four types of unit can be connected to enable the measurement
of up to 120 channels with one Memory HiLogger. Furthermore, the synchronous
operation of a maximum of five Memory HiLoggers enables you to build a sys-
tem with up to 600 channels. The instrument transfers the measurement data to
the computer in real time. The instrument can also be used not just for computer
based data collection but also as a standalone instrument. (Measurement with
just this instrument is referred to as “standalone” within this manual.) In either
case, set the measurement conditions with the supplied software Logger Utility.
See "2.1 Installing Logger Utility" (p. 18).
Overview Chapter 1
1.1 Product Overview
Data is transferred
in real time
USB or LAN
Computer Based Standalone
Data is saved to
a CF card
Start measurement
Stop measurement
Measurement is started and
stopped with the keys on
the instrument.
Optional 9683 Connection Cable
(for synchronization)
Maximum of
five loggers
Example of Connecting Multiple Memory HiLoggers
USB or LAN
HUB
