8.1 Saving and Reading Measurement Data
167
8
Chapter 8 Saving and Reading Data
This section describes outputting the measurement data obtained by Logger
Utility to Excel.
1. Click [Output Data to Excel] from the File menu to display the Microsoft
Excel dialog box.
2. Select the target sheet for which convert measurement data.
Click check boxes to select the channels to be converted.
3. Specify the range for converting data with [Range to Convert].
4. Enter a value for [Thinning Number] by clicking the spin button.
If the value for the thinning number is 1, all data is converted. In other cases,
data is thinned at the specified interval and then converted.
8.1.2 Converting Measurement Data to an Excel File
Selectable
Items
Explanations
Whole Range Convert waveform data for whole range.
Between A-B
Convert waveform data for the section between cursor A and cur-
sor B. If there is only on cursor, the data from the cursor position to
the end is converted.
Excel might cause an out of memory error when there are a lot of cells. In this
case, please narrow the range to convert by A-B cursor.
