Hioki 8423 User Manual

10.6 IP Address
191
Chapter 10 Setting Method for Logger
10
This section describes setting the IP address of the instrument for LAN commu-
nication. See "LAN Connection Examples" (p. 71).
1. Turn the power on while pressing
and then release the key
when the model name and version
appear in the display area.
The instrument enters setting mode.
2. Press multiple times until the following IP address setting screen
appears.
3. Press to move the flashing cursor to the position to change.
Each press of the key moves the flashing cursor to the right.
4. Press to increase the value at the flashing cursor in increments of 1.
The value cannot be decremented.
5. Press to move the flashing cursor to [SET], and press to con-
firm the setting.
6. Press multiple times until the following setting mode end screen
appears.
7. Press to end setting mode.
An address for identifying individual devices connected to a network. Set an IP
address that is not a duplicate of that of another device. If DHCP is set to ON,
the setting is configured automatically.
10.6 IP Address

Hioki 8423 Specifications

General

Interface	RS-232C
Storage Media	Internal memory
Accuracy	±0.1% of full scale
Power Supply	AC adapter or AA alkaline batteries x 4
Thermocouple	K, J, T, E, R, S, B, N
Measurement Parameters	Voltage
Current Range	Requires clamp-on sensor (optional)
Operating Temperature	0°C to 40°C
