11.1 Displaying the Main Page
209
9
Chapter 11 Communications (HTTP/FTP)
11
You can display the main page in a browser on a computer and then control the
instrument. The HTTP/FTP function can only be used during communication via
a LAN. It is not available during communication via a USB.
1. Launch Internet Explorer.
2. Enter the instrument's address in the address bar and the 8423 Main Page
will be displayed.
(Enter http://192.168.1.2 here)
3. Click [SETTING PAGE].
4. The instrument's screen will be displayed in the web browser as-is.
Communications
(HTTP/FTP) Chapter 11
11.1 Displaying the Main Page
• Internet Explorer version 4 or later is supported.
Netscape Navigator can also be used, but in such case, part of the browser
screen may be unable to operate normally.
• Operation using the HTTP server or FTP server is not possible while measure-
ment is being performed with Logger Utility.
If the HTTP screen does not appear
Choose [Tools] - [Internet Options] on the Internet Explorer tool bar and click
on the
[Advanced] tab. Check the box for [Use HTTP1.1] and remove the
check from the box for
[Use HTTP1.1 through proxy connections]. if it is
checked. Also, choose the
[Connections] tab of [Internet Options], click on the
[LAN Settings] button, and remove the check from the box for [Use a proxy
server]
if it is checked. See "Communication Problems" (p. 73).
To Next Page
