12.2 Application Software
219
Chapter 12 Specifications
12
General Specifications
Function Specifications
Real-time Data Collection
Data Collection Settings
12.2 Application Software
Supplied Media One CD
Operating Environment A computer that satisfies the following conditions
CPU : Pentium III (500 MHz) or better
Memory : At least 512 MB
Interface : Ethernet or USB
OS : Windows 2000 (with SP4 or later)
Windows XP (with SP2 or later)
Windows Vista
Windows 7
Display : 1024 x 768 dots or better, 65536 colors or more
Compatible Measuring
Instrument
HIOKI 8423 Memory HiLogger, 8430 Memory HiLogger,
LR8400, LR8401, LR8402 Memory HiLogger, LR8431 Memory HiLogger
Overview The control of the measurement of multiple loggers connected by LAN or USB, and the
reception, display, and saving of the waveform data in real time (Total recording sam-
ple count: Up to 10 M of samples)
Controllable Memory HiLog-
gers
5
Data Collection System 1 system (running multiple instances of the application software facilitates multiple sys-
tem collection)
Display Format • Waveforms (split time-axis display is possible)
• Numerical values (logging)
• Alarms
The above items can be displayed simultaneously
Numerical Value Monitor
Display
Display in a separate window is possible.
Scroll Waveforms can be scrolled during measurement
Data Save Destination Real-time data collection file (LUW format)
Event Mark Recording during measurement is possible
Settings The data collection settings of the Memory HiLogger unit can be configured
Save The settings of multiple loggers can be saved together to one file (LUS format)
Sending and Receiving of
Main Unit Settings
Possible
