7.5 Event Mark Function
154
You can search for event marks.
1. Click the [Event] tab on the right side of the main screen to open the settings window.
2. Set event mark to ON.
3. When an event mark is selected from the event mark list and the [Display This Position] button
is clicked, the instrument will locate the specified event mark that is specified, jumps to its
position and displays the waveforms. This function can also be performed by double-clicking
the event mark on the event mark list.
7.5.2 Searching for and Editing Event Marks
(1) Click
Event Mark List
(2) Click
Selected event mark and its posi-
tion
Comment input field (optional)
You can select the illustration of
the event mark.
This button moves cursor A to the position of the selected event mark.
(This operation can also be performed by right double-clicking an event
mark in the list.)
(1) Click
This button deletes the selected event mark.
(2) Click
This button deletes all event marks.
To Next Page
