3.5 Connecting a Communication Cable
43
7
3
Chapter 3 Setting Up the Instrument
A computer is used to set the instrument, record measurement data, and ana-
lyze recorded data. Use the USB cable or 9642 LAN Cable to connect the instru-
ment and computer.
When you want to measure via USB, connect the instrument and computer with
the supplied USB cable. To ensure stable communication, do not connect the
LAN cable when measuring via USB.
3.5 Connecting a Communication Cable
• To avoid a malfunction, do not connect or disconnect the USB cable or LAN
cable during operation.
• To ensure stable communication, connect either just the USB cable or just the
LAN cable and then take measurements.
Be sure to install the supplied software Logger Utility on the computer
before connecting the USB cable to the computer for the first time.
3.5.1 Connecting the USB Cable
USB cable
USB connector
When connecting the instrument and computer directly on a one-to-one-basis:
When connecting multiple Memory HiLoggers to a computer:
HUB
USB cable
Use a USB hub or connect the Memory
HiLoggers to available USB ports.
