12.4 Dimension Diagrams
228
12.4 Dimension Diagrams
133 ± 2
5 ± 2
67 ± 2
125 ± 2
Unit: mm
133 ± 2
5 ± 2
38.5 ± 2
97.7 ± 2
38.5 ± 2
5 ± 2
67.1 ± 1
4.5
67.1 ± 1
4.5
DIN rail
(35mm width)
DIN rail
(35mm width)
Model 8423 Memory HiLogger
Main Unit
Unit
