9.6 Print Example
181
Chapter 9 Printing
9
Print Example 1: Print Continuous Pages (during selection of
waveform printing option)
9.6 Print Example
Upper limit
values
Lower limit
values
Channel
information
Event Mark
CH Maker
Gauge
Sampling
Speed
Show the positions of the printing
ranges of all the waveforms.
All the waveforms
Cursor Comment (p. 84)
Comment (p. 84)

Hioki 8423 Specifications

General

Interface	RS-232C
Storage Media	Internal memory
Accuracy	±0.1% of full scale
Power Supply	AC adapter or AA alkaline batteries x 4
Thermocouple	K, J, T, E, R, S, B, N
Measurement Parameters	Voltage
Current Range	Requires clamp-on sensor (optional)
Operating Temperature	0°C to 40°C
