10.11 Self Check
202
This section describes checking the display area of the instrument.
1. Turn the power on while pressing
and then release the key
when the model name and version
appear in the display area.
The instrument enters setting mode.
2. Press multiple times until the following LCD check screen appears.
3. Each press of changes the display in the following order.
4. Press to display the result in the display area.
5. Press to end the display of the result.
6. Press multiple times until the following setting mode end screen
appears.
7. Press to end setting mode.
10.11.6 LCD Check
The top line is
blank
The bottom line
is blank
The top line is
black
The bottom line
is black
The top line displays
characters
The bottom line dis-
plays characters
If there is an error with the display, submit the instrument for repairs.
