10.12 Displaying Individual Version Information
204
This section describes displaying the FPGA versions of the instrument and each
unit connected to the instrument.
1. Turn the power on while pressing
and then release the key
when the model name and version
appear in the display area.
The instrument enters setting mode.
2. Press multiple times until the following FPGA version screen
appears.
3. Confirm the version.
4. Press multiple times until the following setting mode end screen
appears.
5. Press to end setting mode.
10.12.2 FPGA Version
This indicates the FPGA version of the 8423 main unit.
The number on the far right indicates the FPGA version of the unit connected on
the immediate left of the 8423 main unit. The number on the far left indicates the
FPGA version of the unit connected at the very end. If no unit is connected, "__"
is displayed.
