12.2 Application Software
220
Waveform Display
Data Conversion
Waveform Calculation
Calculations
Search
Print
Supported Files Real-time data collection file (LUW format), Main unit measurement file (MEM format)
Display Format • Waveforms (split time-axis display is possible)
• Simultaneous display of numerical values (logging) is possible
Maximum Number of
Channels
600 channels (measured) + 60 channels (waveform calculation)
Waveform Display Sheets The waveform of each channel can be displayed on any of the ten sheets
Scroll Possible
Event Mark Recording Possible
Cursors Cursors A and B can be used to display voltage values at the cursor positions.
Hard Copy A hard copy of the main screen is possible
List Display Display in a separate window is possible.
Applicable Data Real-time data collection file (LUW format), Main unit measurement file (MEM format)
Conversion Section All data, specified section
Conversion Format CSV format (comma delimited, space delimited, tab delimited), transfer to Excel sheet
Data Thinning Simple thinning with any thinning number
Calculation Items Four arithmetic operations (+, -, *, /)
Number of calculation channel 60 channels
Applicable Data Real-time data collection file (LUW format), Main unit measurement file (MEM format),
Data being collected in real time, Waveform calculation data
Calculation Items Average value, peak value, maximum value, time to maximum value, minimum value,
time to minimum value, On time, Off time, On count, Off count, standard deviation,
integral, area value and integration
Applicable Data Real-time data collection file (LUW format), Main unit measurement file (MEM format)
Search Mode Event mark, date and time, maximum position, minimum position, local maximum posi-
tion, local minimum position, alarm position, level, window, and variation
Applicable Printer Printer applicable to the using OS
Applicable Data Real-time data collection file (LUW format), Main unit measurement file (MEM format)
Print Format Waveform image, Report print, List print (Channel settings, Event, Cursor value)
Print Area All area, Specified area by A-B cursor
Print Preview Available
