8.1 Saving and Reading Measurement Data
168
5. Select the desired item from the list for [Time Axis Format].
6. Select the desire item from the list for [Save Format] since a line limit
changes by version of Excel.
7. Click [OK] and then a conversion is started.
If you need to save the data, save the data on excel.
Example of saving as an Excel file:
Selectable
Items
Explanations
Absolute Time
Convert time data with the absolute time measurement started set
as the reference.
Relative Time Convert time data with the time measurement started set to 0.
Second
Convert time data with the time measurement started set to 0 and
indicated in seconds.
Point
Convert time data with the time measurement started set to 0 and
as the number of data points.
Selectable Items Explanations
Split by 240ch
∗60,000 data
(Excel97-2003)
Measurement data is divided with 240 channels ∗
60,000samples.
Split by 600ch
∗1,000,000 data
(Excel2007)
Measurement data is divided with 600 channels ∗
1,000,000samples.
