1.2 Features
11
1
Chapter 1 Overview
Connecting multiple Memory HiLoggers with optional 9683 Connection Cable
(for synchronization) allows for synchronized measurement. See "3.7 Connect-
ing Synchronization Cables" (p. 48).
The instrument is compatible with LAN 100BASE-TX and USB2.0. A computer
and Memory HiLogger can be connected to enable the supplied software Logger
Utility to be used to control the Memory HiLogger and collect data.
This allows you to save the setting conditions and the measurement data in real
time to a CF card. While data is being saved to the CF card in real time, you can
replace the CF card without stopping measurement. Furthermore, the risk of files
being damaged as a result of, for instance, an unexpected power outage is
greatly reduced because internal backup circuitry is used to process the ending
of files when there is a power outage.
The Memory HiLogger can be controlled by inputting a signal from an external
device. This allows for the starting and stopping of measurement, external sam-
pling, and external triggers.
After settings such as the measurement conditions have been configured from
Logger Utility, you can disconnect the computer and then start/stop measure-
ment with or on the instrument.
Synchronized Measurement
Equipped with LAN & USB Interfaces
Equipped with CF Card Slot
Equipped with External Control Input Terminals
Standalone Measurement
