Hioki 8423 - Page 230

12.3 Unit Specification
222
Measurement Range/ Measurable Range/ Resolution/ Measurement Accuracy
*1 Using the 10 V f.s. range, the upper limit is set at 5V and the lower limit is set
at 1V. Resolution is the same as that for the 10V f.s. fange.
*2 JIS C 1602-1995 *3 ASTM E-988-96
Recording Interval and Cutoff Frequency Table
Measurement
Parameter
Measurement Range
Measurable
Range
Maximum
Resolution
Measurement Accuracy
Voltage
100 mV f.s. -150 to 150 mV 5 μV
± 0.1% f.s.
1 V f.s. -1.5 to 1.5 V 50 μV
10 V f.s. -15 to 15 V 500 μV
20 V f.s. -30 to 30 V 1 mV
100 V f.s. -100 to 100 V 5 mV
1-5 V f.s.
*1
1 to 5 V 500 μV
Thermocouple
(not including
increased accu-
racy of reference
junction compen-
sation)
K
*2
100°C f.s. -100 to 100°C 0.01°C
± 0.05%f.s. ± 1°C
500°C f.s. -200 to 500°C 0.05°C
2000°C f.s. -200 to 1350°C 0.1°C
E
*2
100°C f.s. -100 to 100°C 0.01°C
500°C f.s. -200 to 500°C 0.05°C
2000°C f.s. -200 to 1000°C 0.1°C
J
*2
100°C f.s. -100 to 100°C 0.01°C
500°C f.s. -200 to 500°C 0.05°C
2000°C f.s. -200 to 1200°C 0.1°C
T
*2
100°C f.s. -100 to 100°C 0.01°C
500°C f.s. -200 to 400°C 0.05°C
2000°C f.s. -200 to 400°C 0.1°C
N
*2
100°C f.s. -100 to 100°C 0.01°C
500°C f.s. -200 to 500°C 0.05°C
2000°C f.s. -200 to 1300°C 0.1°C
R
*2
100°C f.s. 0 to 100°C 0.01°C
± 0.05% f.s.± 3.5°C
(0 to <400°C)
(except Type B, for which accu-
racy below 400°C is not guaran-
teed)
± 0.05% f.s. ± 2°C (400°C min)
500°C f.s. 0 to 500°C 0.05°C
2000°C f.s. 0 to 1700°C 0.1°C
S
*2
100°C f.s. 0 to 100°C 0.01°C
500°C f.s. 0 to 500°C 0.05°C
2000°C f.s. 0 to 1700°C 0.1°C
B
*2
2000°C f.s. 0 to 1800°C 0.1°C
W
*3
(Wre
5-26)
100°C f.s. 0 to 100°C 0.01°C
500°C f.s. 0 to 500°C 0.05°C
2000°C f.s. 0 to 2000°C 0.1°C
Recording Interval
Digital Filter
10 ms 20 ms 50 ms 100 ms 200 ms 500 ms 1 s 2 s 5 s 10 s
20 s
or more
50 Hz
20.833
kHz
9 kHz 3.375
kHz
1.687
kHz
852 Hz 330.6 Hz 165.3 Hz 83.08 Hz 50 Hz 50 Hz 10 Hz
60 Hz
20.833
kHz
9 kHz 3.375
kHz
1.687
kHz
852 Hz 330.6 Hz 165.3 Hz 83.08 Hz 60 Hz 60 Hz 10 Hz
OFF
20.833
kHz
20.833
kHz
20.833
kHz
20.833
kHz
20.833
kHz
20.833
kHz
20.833
kHz
20.833
kHz
20.833
kHz
20.833
kHz
20.833
kHz
