12.3 Unit Specification
224
Measurment Range/ Measurable Range/ Resolution/ Measurement Accuracy
Measurement
Parameter
Measurement Range Measurable Range
Maximum
Resolution
Measurement Accuracy
Voltage 100 mV f.s. -150 to 150 mV 5 μV ± 0.1% f.s.
1 V f.s. -1.5 to 1.5 V 50 μV
10 V f.s. -15 to 15 V 500 μV
20 V f.s. -30 to 30 V 1 mV
100 V f.s. -60 to 60 V 5 mV
1-5 V f.s.
*1
1 to 5 V 500 μV
Thermocouple (not
including increased
accuracy of refer-
ence junction com-
pensation)
K
*2
100°C f.s. -100 to 100°C 0.01°C ± 0.05% f.s. ± 1°C
500°C f.s. -200 to 500°C 0.05°C
2000°C f.s. -200 to 1350°C 0.1°C
E
*2
100°C f.s. -100 to 100°C 0.01°C
500°C f.s. -200 to 500°C 0.05°C
2000°C f.s. -200 to 1000°C 0.1°C
J
*2
100°C f.s. -100 to 100°C 0.01°C
500°C f.s. -200 to 500°C 0.05°C
2000°C f.s. -200 to 1200°C 0.1°C
T
*2
100°C f.s. -100 to 100°C 0.01°C
500°C f.s. -200 to 400°C 0.05°C
2000°C f.s. -200 to 400°C 0.1°C
N
*2
100°C f.s. -100 to 100°C 0.01°C
500°C f.s. -200 to 500°C 0.05°C
2000°C f.s. -200 to 1300°C 0.1°C
R
*2
100°C f.s. 0 to 100°C 0.01°C ± 0.05% f.s. ± 3.5°C
(0 to <400°C)
(except Type B, for which accuracy
below 400°C is not guaranteed)
±0.05% f.s. ± 2°C (400°C min.)
500°C f.s. 0 to 500°C 0.05°C
2000°C f.s. 0 to 1700°C 0.1°C
S
*2
100°C f.s. 0 to 100°C 0.01°C
500°C f.s. 0 to 500°C 0.05°C
2000°C f.s. 0 to 1700°C 0.1°C
B
*2
2000°C f.s. 0 to 1800°C 0.1°C
W
*3
(Wre
5-26)
100°C f.s. 0 to 100°C 0.01°C
500°C f.s. 0 to 500°C 0.05°C
2000°C f.s. 0 to 2000°C 0.1°C
Resistance
temperature detector
Pt100
*4
100°C f.s. -100 to 100°C 0.01°C ± 0.05% f.s. ± 0.5°C
500°C f.s. -200 to 500°C 0.05°C
2000°C f.s. -200 to 800°C 0.1°C
JPt100
*5
100°C f.s. -100 to 100°C 0.01°C
500°C f.s. -200 to 500°C 0.05°C
2000°C f.s. -200 to 500°C 0.1°C
Humidity 100%RH 5.0 to 95.0%RH 0.1%RH See table on next page
(including accuracy of 9701 HUMID-
ITY SENSOR)
