5.4 Advanced Settings for Each Channel
90
Measurement is possible when an 8948 Voltage/Temp Unit or 8949 Universal
Unit is connected. Set the range.
*1: The range for the 8949 Universal Unit is -60 to 60 V.
*2: The 1-5 V f.s. range for voltage measurement is intended for use with mea-
surement devices that provide an output of 1-5 V at 4-20 mA. The upper
limit 5 V and the lower limit 1 V of the 10 V f.s range is set automatically. The
measurement accuracy is the same as for 10 Vf.s. When inputting a 4-20 mA
electric current, connect a 250 Ω resistance as a shunt resistance across the
+ and - analog input terminals. See "3.2.2 Connecting a Cable" (p. 37).
When Voltage is Selected
Selectable Items Measurable Ranges Maximum Resolution
100 mV f.s. -150 to 150 mV
5
μV
1 V f.s. -1.5 to 1.5 V
50
μV
10 V f.s. -15 to 15 V
500 μV
20 V f.s. -30 to 30 V 1 mV
100 V f.s. -100 to 100 V
*1
5 mV
1-5 V f.s.
*2
1 to 5 V
500
μV
