Color Change and Non-Thermal Sensitive Resin Example 217
User Guide v 2.0 — March 2023 Color Change
13.4.1.1 Color Change and Non-Thermal Sensitive Resin Example
The steps and figures that follow show the instructions only for sequence #1 in the process
flowcharts (Figure 13-5), as displayed on the Altanium controller’s screens. All four
sequences in Figure 13-5 must be done to complete the purge, but the steps that follow
guide you through sequence #1 as an example.
NOTE: As you start each sequence in Figure 13-5, look through the sequence steps to see if
the "Husky Machine Connection" or "Ultra Purge Booster" settings should be enabled
or not enabled. Set them, as necessary, before you touch the Ultra Purge Sequence
panel Start button.
1. Configure the settings in the Ultra Purge Settings panel for the resin that you will use.
2. Touch the system Start button, if necessary.
3. Wait for the system status to show Running mode, if necessary.
4. Touch the Ultra Purge Sequence panel Start button.
Figure 13-5 Flowcharts - Color Change and Non-Thermal Sensitive Resin
