Husky Altanium Delta5 - Part Count Base Connector ID; Remote Load Base Connector ID

Part Count Base Connector ID 259
User Guide v 2.0 — March 2023 System Options
14.7.3 Part Count Base Connector ID
The part count base connector pins are identified in Table 14-13.
14.7.4 Remote Load Base Connector ID
The remote load base connector pins are identified in Table 14-14.
Table 14-13 Part Count Base Connector Pins
Connector/Pin Field Cable Wire Color Signal Function
Part Count / A BLK Reset parts counter
Part Count / B WHT Count Parts
Part Count / C RED 12 V+
Part Count / D GRN 0 V
Part Count / E BRN Sack full
Part Count / F BLU Sack full
Table 14-14 Remote Load Base Connector Pins
Connector/Pin Field Cable Wire Color Signal Function
Remote Load / A WHT Load setup
Remote Load / B WHT/BLK Setup B0
Remote Load / C BLK Setup B1
Remote Load / D BLK/WHT Setup B2
Remote Load / E BLU Setup B3
Remote Load / F BLU/WHT Setup B4
Remote Load / G BLU/BLK Setup B5
Remote Load / H GRN 12 V+
Remote Load / J GRN/BLK 12 V+
Remote Load / K GRN/WHT 0 V
Remote Load / L ORG 0 V
Remote Load / M ORG/BLK Remote file loaded
Remote Load / N RED Remote file loaded
